TeenyF4 Pro Flytower F4 1-2S, 5A, 16x16mm
Key Features
Support programmable LED_strip
Support BLheli/BLHELI_S suite Pass-through ready
Support PPM, Oneshot125,Oneshot42,Multishot, Dshot150, Dshot300, Dshot600
Default Dshot600
Built-in voltage detection, alarm
Built-in Betaflight-OSD
Buzzer solder pin
LED_STRIP connector
Specification
Flight Controller:
Model: TeenyF4 Pro
Processor: STM32F405RGT6
Sensor: MPU-6000 ( connected by SPI)
Firmware Version: betaflight_3.2.0_OMNIBUSF4SD
Built-in betaflgiht OSD
Built-in Buck-Boost Converter
Input Voltage: 1-2S Lipo
Receiver: PPM, IBUS, SBUS, DSM2, DSMX etc.
Size: 20*20mm
Mounting hole: 16*16mm
Mount Hole Diameter: 2mm ( M2 )
Weight: 2.2g
5A 4 in 1 ESC: ( Bottom )
Name: Teenypro 4 In 1 5A BLHeli_S ESC
Mode: Teenypro
Input Voltage: 1-2S Lipo
Con. Current: 5A
Peak Current: 7A (5 Seconds)
Firmware: BLHELI_S
Processor: SILABS EFM8BB21F16G
BEC: NO
Size: 23x27mm (includes solder pad)
Mounting Holes: 16x16mm (M2)
Weight: 2.1g
Firmware Target: BLHeli_S S_H_50_REV16_7
Support Dshot150 Dshot300 Dshot600 Oneshot125 Multishot PWM
Setting up your RX
SBUS/IBUS/DSMX receiver please configure RX1 (UART1) as input, and enable Serial_RX
PPM receiver don’t need to enable Serial_RX
DSM/DSM2/DSMX receiver power from 3.3V
Setting up your RX
SBUS/IBUS/DSMX receiver please configure RX1 (UART1) as input, and enable Serial_RX
PPM receiver don’t need to enable Serial_RX
DSM/DSM2/DSMX receiver power from 3.3V
SBUS and PPM receiver power from 5V
Included:
1x F4 Flight Controller Board
1x 5A 4 In 1 ESC
1x 6P Cable
8x M2*5+5 Nylon column
8x M2 Nuts
8x M2 Screw
